To supply one DAF FA LF – 210, 4×2 haulage chassis cab, 5.0m wheelbase plated at 12 tonnes GVW. All to the manufacturer’s standard specification and generally in accordance with the enclosed specification sheet.
H3279 Brilliant White Day cab
Cab suspension rubber & mechanical Adaptive Cruise Control with FCW & AEBS-3
Lane Departure Warning System Front: 4.50t, parabolic, F48
Goodyear F1,245/70R17.5GO KMAXS
R1,245/70R17.5GO KMAXD Exhaust emission Euro 6
OBD, Euro VI Step E Standard component location
EAS unit right, discharge right rearward Plastic fuel tank 110l
Fuel tank left Tank for AdBlue 30l, right hand side chassis
Battery box left, no spare wheel carrier DAF Connect
Standard Warranty – 1yr Full – 2nd yr DL – 1yr BD Warranty Plus – 1yr Vehicle 3yr Driveline
External sun visor green translucent Halogen head lights
Fog lights Kerb view window co driver door
Side no glass/rear single glass 6 mirrors
Roof air deflector prepared Driver seat: luxury air suspended
Arm rest driver seat Dual mate seat, velour
No storage engine tunnel Air conditioning
Tachograph digital, VDO 1C version 1 Speed limiter setting 85km/h nominal
FM/AM/DAB/DAB+ radio/CD player, 2 speakers Air bag (driver) & 2 seat belt tensioners
Reverse warning Manual main switch
Rear: 8.50t, air suspension, SR8.22 Engine PX-5, 153 kW/208 hp. Cab badge: 210
Automatic gearbox Powerline, 8 speed 8-speed Powerline 8AP800 overdrive, 4.89-0.64
Rear axle ratio 3.73 Mechanical differential lock
Wheelbase 5.00m/rear overhang 2.46m Type plate related solo appl., trailer max 3500kg
Electric trailer connection 24V/2×7 pins Analogue body signals & warnings
Analogue engine speed control connector chassis Body attachment BAM 1, loose consoles supply
Analogue gearbox PTO control, no first gearbox PTO Alternator 100 A, batteries 2x 125 Ah
Driveline related technical GCM = GVM+3500kg Standard fuel quantity +30 litres To include: factory delivery charges, PDI, number plates, calibrate & seal tacho, valet & final delivery
